| Swing Over Bed | 17″ |
|---|---|
| Swing Over Cross Slide | 10.2″ |
| Swing Over Gap | 22″ |
| Width of Bed | 12-1/4″ |
| Distance Between Centers | 60″ |
| Cross Slide Travel | 9.26″ |
| Top Slide Travel | 4″ |
| Spindle Speeds | 12 |
| Spindle Speed Range | 32-1800 RPM |
| Through Hole Diameter | 2-1/32″ |
| Spindle Nose | D1-6 Camlock |
| Spindle Bore Taper | MT#6 |
| Thread – Standard (Whit-worth) | 65 (1-5/8 to 72) TPI |
| Thread – Metric Pitch | 28 (0.5 to 20) mm |
| Longitudinal Feed | 0.0014″ – 0.0439″ in/rev |
| Cross Feed | 0.0010”-0.0330” in/rev |
| Lead Screw Diameter | 1.33″ |
| Threading Pitch | 4 TPI |
| Quill Travel | 4-3/4″ |
| Quill Diameter | 2.36” |
| Quill Bore Taper | MT#4 |
| Main Motor | 6 or 4 HP (2 Speed, 3-phase) |
| Coolant Pump Motor | 1/8 HP |
| Machine Dimension | 115″ x 40″ x 47″ |
| Packing Dimension | 125″ x 44″ x 62″ |
| Machine weight | 4450 lbs |
| Packing weight | 4670 lbs |
