| Swing Over Bed | 18″ |
|---|---|
| Swing Over Cross Slide | 10.8″ |
| Swing Over Gap | 27.2″ |
| Width of Bed | 12″ |
| Distance Between Centers | 40″ |
| Cross Slide Travel | 11.4″ |
| Top Slide Travel | 4.7″ |
| Spindle Speeds | 12 |
| Spindle Speed Range | 25-2000 RPM |
| Through Hole Diameter | 3.2″ |
| Spindle Nose | D1-8 |
| Spindle Bore Taper | MT#5 w/ sleeve |
| Thread – Standard (Whit-worth) | 4-112 (50NOS) |
| Thread – Metric Pitch | 24 (0.25 to 7) mm |
| Longitudinal Feed | 0.0011″ – 0.0316″ |
| Cross Feed | 0.00024″ – 0.0068″ in/rev |
| Lead Screw Diameter | 1.38″ |
| Threading Pitch | 4 TPI |
| Quill Travel | 4.7″ |
| Quill Diameter | 2.36” |
| Quill Bore Taper | MT#4 |
| Main Motor | 7.3 HP |
| Coolant Pump Motor | 1/8 HP |
| Machine Dimension | 88″ x 36″ x 51″ |
| Packing Dimension | 93″ x 39″ x 64″ |
| Machine weight | 3813 lbs |
| Packing weight | 4365 lbs |
