Commonwealth Industrial / Kent USA KLS-26120C

Kent USA KLS-26120C

  • 10 HP main spindle motor, 12 speeds
  • D1-8 camlock, 4.1” spindle bore
  • Hardened and ground gears and bedways
  • Jog button, 4-way rapid traverse
  • Mechanical clutch style headstock
  • Inch dials and leadscrews
  • Centralized lube system in headstock
  • Safety Foot brake
Swing Over Bed 26″
Swing Over Cross Slide 16.5″
Swing Over Gap 34″
Width of Bed 16″
Distance Between Centers 120″
Cross Slide Travel 12.2″
Top Slide Travel 5.75″
Spindle Speeds 12
Spindle Speed Range 36-1600 RPM
Through Hole Diameter 4.12″
Spindle Nose D1-8 Camlock
Spindle Bore Taper MT#6
Thread – Standard (Whit-worth) 32 (2–28) TPI
Thread – Metric Pitch 18 (1.25–14) mm
Longitudinal Feed 0.0024”-0.0992” in/rev
Cross Feed 0.0011”-0.042” in/rev
Lead Screw Diameter 1-9/16″
Threading Pitch 2 TPI
Quill Travel 6″
Quill Diameter 2.9″
Quill Bore Taper MT#5
Main Motor 10 HP (3-phase)
Coolant Pump Motor 1/8 HP (3-phase)
Machine Dimension 177″ x 45″ x 57″
Packing Dimension 185″ x 55″ x 84″
Machine weight 8580 lbs
Packing weight 9180 lbs

Standard Accessories

  • 3-jaw chuck
  • 4-jaw chuck
  • Face plate
  • Steady rest
  • Follow rest
  • Thread chasing dial toolbox with standard tools

Optional Accessories

  • Digital readout system (View Brochure)
  • 5C lever style collet closer
  • Royal spindle type live center
  • Live center set with interchangeable tips
  • BTC 3-jaw chuck with back plate
  • Transformer for 440V power
  • Rustlick lubricant
